Automated Methane Emissions Monitoring That Cuts LDAR Costs and Accelerates Compliance
MethaneTrack™ continuously detects, quantifies, and reports methane emissions — helping operators save time, reduce costs, and advance their Net Zero goals.
Manual LDAR Creates Inefficiencies That Cost Time and Money
Periodic leak surveys consume valuable time and manpower that could be spent on higher-impact maintenance and repair work and leave long gaps between inspections, driving higher LDAR program costs, delay repairs, and create blind spots in emissions reporting.
Inefficient Use of Skilled Labor
Highly trained technicians spend hours driving to sites for routine surveys instead of addressing known issues.
Lost Product and Higher Risk
Leaks that occur between inspections can result in product loss and regulatory fines.
Data Gaps and Missed Insights
Operators lack visibility into true emissions trends and equipment health.
Rising Costs and Lower ROI
Manual scheduling, redundant surveys, and delayed response all increase LDAR program cost without improving outcomes.
Inefficient Use of Skilled Labor
Highly trained technicians spend hours driving to sites for routine surveys instead of addressing known issues.
Lost Product and Higher Risk
Leaks that occur between inspections can result in product loss and regulatory fines.
Data Gaps and Missed Insights
Operators lack visibility into true emissions trends and equipment health.
Rising Costs and Lower ROI
Manual scheduling, redundant surveys, and delayed response all increase LDAR program cost without improving outcomes.
Introducing MethaneTrack™
Improve operational efficiency and quickly mitigate emission events with real-time detection, localization, and quantification of methane emissions*.
Reduce the costs of LDAR with real-time emissions data
Receive automatic alerts with emission location and volume
Comprehensive reporting supports OGMP 2.0, EPA, and Fit for 55 regulations
Gain insights on failure causes for continual operational improvement
Intrinsically Safe, Class 1, Div. 1, Zone 0 certified FM, CSA, IECEx, ATEX, and IP65+
Purpose-built for harsh environments: -40°C to 75°C 100%RH
Virtually maintenance-free with 5-year battery life/15-year sensor life and no required field califbration
A typical site installation can be completed by a single technician in just a few hours
The system is also available in an EmissionsTrack™ version for multi-gas leak detection applications, including Hydrogen.
How it Works
The MethaneTrack™ system consists of a gateway, an anemometer, and multiple wireless sensors deployed at each site. Because there is no need for wiring, a typical site installation can be completed by a single technician in just a few hours.
MethaneTrack™ wireless sensors sample the surrounding air, measuring gas concentrations.
Encrypted data is transmitted to the cloud, where proprietary Leak Source Isolation™ algorithms analyze the data, along with the wind data from the anemometer, to quantify the leak size and pinpoint the leak location.
MethaneTrack’s™ dashboard analytics and reporting platform visualizes the data and automatically alerts the right people that an emission event has occurred.
WATCH THE VIDEO
Learn more about methane monitoring with MethaneTrack™
Who Uses MethaneTrack™ for Methane Monitoring?
Oil & Gas Companies
- Upstream: Drilling operations, offshore platforms, and exploration sites.
- Midstream: Monitoring of pipelines, compressor stations, Isolation valves, and LNG, regassification and natural gas processing facilities.
- Downstream: Methane detection in refineries, chemical plants, and natural gas distribution facilities.
Waste Management
Monitoring of landfill gas emissions to manage and control methane emissions.
Landfill gas collection and utilization for energy generation.
Compliance monitoring in waste disposal sites to minimize environmental impact.
Agriculture
- Monitoring methane emissions from livestock and agricultural processes to reduce greenhouse gas emissions.
- Biogas production and optimization in agricultural settings.
Environmental compliance in agriculture to manage methane emissions from various farming activities.
Hydrogen
- Monitoring and detection of hydrogen emissions in industrial processes, including hydrogen production, storage, and transportation.
- Hydrogen fuel cell production and distribution facilities.
- Hydrogen energy generation, including power plants and refueling stations.
CUSTOMER SUCCESS
Proven. Deployed. Global.
With 16,000+ devices deployed across 22 countries, both onshore and offshore, NevadaNano is ready to help operators in the region and around the world detect, localize, and reduce methane emissions – improving efficiency and supporting NetZero goals.
500+
Active Sites
Operating sites installed or on order
30+
Customers in Trial
Active pilot programs across multiple regions
22
Countries
With Inmetro certification for easy deployment
4
Market Segments
Upstream, midstream, downstream, and offshore operations
Case Study
MethaneTrack™ Customer in Permian Basin Achieves 95% Reduction in Methane Emissions
Case Study
Global Energy Producer in Europe Chooses MethaneTrack™ to Monitor Floating Roof Tanks
Case Study
MethaneTrack™ Helps Customer Identify and Control Leaks from On-Site Compressors
The MethaneTrack™ Wireless Sensor:
Precise, portable, and virtually maintenance-free
A complete “Fix-and-Forget” solution
- No field calibration
Immunity to saturation and poisoning and no field calibration eliminates the prohibitive cost of quarterly calibration trips & sensor replacements.
- Highly accurate detection powered by The MPS™
Detection range from 50 to 1M ppm with built-in environmental compensation for temperature, relative humidity, and pressure for near-zero false positives. - Very wide operating range & self-testing capability
-40°C to 75°C operating range with up to 100% relative humidity. Built-In Self-Test (BIST) capability continuously evaluates the system to ensure it is operating to specification. - 5-year battery life and 15-year sensor life
No wiring and long battery and sensor life reduces the need for frequent on-site visits and ensures uninterrupted monitoring.
- Certified as Intrinsically Safe
Class 1, Div. 1 and Zone 0 certified and global safety certifications such as FM, CSA, IECEx, ATEX, and IP65+.
Simple and efficient installation in minutes
- Mounted onto existing infrastructure.
- No need for wiring.
- A typical site installation can be completed by a single technician in just a few hours – enabling installation of several sites per day per installer.
WITH PROXIMITY COMES ACCURACY
Close-Proximity Continuous Monitoring™
MethaneTrack™ wireless sensors are certified Intrinsically Safe, which enables immediate detection to obtain the most precise measurements of emission location and emission rates, due to proximity to the emission source.
- Immediate detection before the wind dilutes and distorts the gas plume
- Ultra-low false positives
- Highly accurate emission localization
- Best in class quantification of the emission rate
DASHBOARD ANALYTICS & REPORTING
Emissions tracking & compliance made easy
Empowering teams to seamlessly work together
- Monitor all levels from enterprise to site and assets.
- Visualize the location and size of emissions.
- Real-time alerts automatically notify the right people.
- Enable users to focus on their area of responsibility.
- Distinguish between operational and fugitive emissions.
Simplified regulatory compliance with customizable reports
- Reduce the cost of tracking and reporting emissions with automatic tabulation of total emissions.
- Validate emissions compliance performance with complete, historical emissions records for individual sites, regions, and countries to support OGMP activity , comply with EPA regulations 0000b & 0000c, and Fit for 55 legislation.
- Meet the needs of different stakeholders such as operators, executives, regulators, and shareholders, with pre-built and configurable reports.
